Discrete, random access, full automated.
Up to constant 180 tests per hour.
Optional for external bar code reader.
30 positions for samples and 60 postions for reagents.
Automatic probe cleaning, liquid level detection, collision protection.
Reversed optic system with 8 wavelengths.
Refrigerated reagent and sample compartment.
English operating system: Windows 2000, windows XP, windows7, windows8, windows10.
Make print format and content freely, provide several common formals.
Special user management password, rational distribution of user operation permissions.
RS-232 standard interface, support for intranet, remote print report.
Optional various databasses, autosave, automatic backup, save all kinds of data permanently.
Real-time monitoring of sample tray, reagent tray, reacting tray; real-time display of reaction temperature, reagent allowance,
reaction curve, calibration curve and quality control chart.
Check and judge reaction endpoint, reaction linear interval, substrate exhaustion, reagent blank absorbance, etc.
Reagents/ sample handing:
Reagent/sample tray: 30 positions for reagents and 60 positions for samples in refrigerated compartment (4~16℃).
Reagent/sample probe: liquid level detection, collision protection and inventory checking.
Probe cleaning: automatic washing for both interior and exterior carry-over<0.1%
Reaction cuvettes cleaning system:
Using unique high efficiency water cleaning method, low carry-over.
Sampling and mixing system:
Sample capacity: 2-30ul, 0.1ul increasing.
Sample probe: sharing with the reagent probe, the inner and auter walls are highly polished, with the function of liquid level
detection, tracking and collision protection, sample probe matching special cleaning liquid, prevent cross contamination.
Reagent capacity: 20-300ul, 0.1ul creasing.
Reagent probe: sharing with the sample probe.
Reagent bottle: reagent bottles with volume of 15ml, 20ml, 30ml, 50ml, 60ml, 70ml can be used, the dead volume is less than 1ml.
Mixing bar: independent mixing bar, special material, surface treatment using teflon, not hanging liquid, thoroughly clean before
and after mixing to prevent cross contamination.
Calibration and quality control:
Quality control type: real time quality control, daily quality control, day to day quality control.
Quality control charts L-J, cumulative, twin plot, the quality control rules are arbitrarily formulated by default to westguard
The calibration type: linear and nonlinear. Logit-4P, Logit-5P, Spline, exponent, polynomial, factor method automatically check
the calibration curve and select the best calibration type of the fitting degree automati-cally.
